CHAPTER 13
Effect Mode Options Descriptions
DL.3 Digital Light User Manual 223
Prism
Effect Mode parameter DMX value = 98
This effect imitates looking at the image through a prism that you define with the Modifier
parameters.
Modifier 1: Sets the number of facets. A DMX value of 0
= no facets. The number of facets
increase from 10 = three facets to 255 (100%) = maximum 16 facets.
Modifier 2: Sets the refraction index from 0 = minimum to 255 = maximum
Modifier 3: Rotates the prism. The default value is 128
(50%). Values below the midpoint
rotate clockwise from 0 = fastest to 127 = slowest rotation. Values above the midpoint rotate
counterclockwise from 129 = fastest to 255 = slowest rotation.
Original Content
Modifier 1 parameter DMX = 255
Modifier 2 parameter DMX = 107
Modifier 3 parameter DMX = 155
