Adjusting the Collage Array with Global Modifier Parameters
The three Global Effects Mode Modifier parameters operate as follows:
The Mo
difier 1 parameter selects which type of Collage array to use from DMX Values 1-127.
The selected size displays in the upper right corner of the grid pattern. A DMX value of 0 = No
co
llage. DMX Values of 126-255 are reserved and default to No collage.
The Mo
difier 2 channel selects which cell of the grid a particular DL.3 or DL.2 fixture will
display. DMX values 0 up to 127 are used to step through grid pattern you selected with the
Modifier 1 channel. As you dial through Modifier 2, the selected cell in the grid is highlighted.
DMX
Value
Array
(W
x H)
DMX
Value
Array
(W x H)
DMX
Value
Array
(W x H)
DMX
Value
Array
(W x H)
DMX
Value
Array
(W x H)
1 2 x 1 26 1 x 6 51 8 x 2 76 10 x 5 101 13 x 6
2 1 x 2 27 6 x 2 52 2 x 8 77 10 x 6 102 13 x 7
3 2 x 2 28 2 x 6 53 8 x 3 78 10 x 7 103 13 x 8
4 3 x 1 29 6 x 3 54 3 x 8 79 10 x 8 104 14 x 1
5 1 x 3 30 3 x 6 55 8 x 4 80 11 x 1 105 14 x 2
6 3 x 2 31 6 x 4 56 4 x 8 81 11 x 2 106 14 x 3
7 2 x 3 32 4 x 6 57 8 x 5 82 11 x 3 107 14 x 4
8 3 x 3 33 6 x 5 58 5 x 8 83 11 x 4 108 14 x 5
9 4 x 1 34 5 x 6 59 8 x 6 84 11 x 5 109 14 x 6
10 1 x 4 35 6 x 6 60 6 x 8 85 11 x 6 110 14 x 7
11 4 x 2 36 7 x 1 61 8 x 7 86 11 x 7 111 14 x 8
12 2 x 4 37
1 x 7 62 7 x 8 87 11 x 8 112 15 x 1
13 4 x 3 38 7 x 2 63 8 x 8 88 12 x 1 113 15 x 2
14 3 x 4 39 2 x 7 64 9 x 1 89 12 x 2 114 15 x 3
15 4 x 4 40 7 x 3 65 9 x 2 90 12 x 3 115 15 x 4
16 5 x 1 41 3 x 7 66 9 x 3 91 12 x 4 116 15 x 5
17 1 x 5 42 7 x 4 67 9 x 4 92 12 x 5 117 15 x 6
18 5 x 2 43 4 x 7 68 9 x 5 93 12 x 6 118 15 x 7
19 2 x 5 44 7 x 5 69 9 x 6 94 12 x 7 119 15 x 8
20 5 x 3 45 5 x 7 70 9 x 7 95 12 x 8 120 16 x 1
21 3 x 5 46 7 x 6 71 9 x 8 96 13 x 1 121 16 x 2
22 5 x 4 47 6 x 7 72 10 x 1 97 13 x 2 122 16 x 3
23 4 x 5 48 7 x 7 73 10 x 2 98 13 x 3 123 16 x 4
24 5 x 5 49 8 x 1 74 10 x 3 99 13 x 4 124 16 x 5
25 6 x 1 50 1 x 8 75 10 x 4 100
13 x 5 125 16 x 6
126 16 x 7
127 16 x 8
