CHAPTER 13
Effect Mode Options Descriptions
220 DL.3 Digital Light User Manual
Prerotation Translation
Effect Mode parameter DMX value = 102
Rotation parameters rotate the center of an ima
ge around the x, y or z axis. The Prerotation
Translation Effect Mode option allows you to position the image in a virtual 3-dimensional space.
Then, when the Rotation parameters for the object are applied, the image will orbit around each
axis from this new position.
NOTE: When this option is applied as a Global effect, it will include any
prerotation translation selected as an Object effect.
Modifier 1: Moves the horizontal position of the image centerpoint from 0 = left edge to 255
(100%) = right edge of output.
Modifier 2: Controls the vertical position of the subpi
cture’s centerpoint from 0=top edge to
255 (100%) = bottom edge of output.
Modifier 3: Controls the size of the picture from 0=smallest to 255 (100%) = largest.
Object Effect Global Effect
