CHAPTER 2
Setup and Configuration
DL.3 Digital Light User Manual 15
Powering On the Fixture
To power on the DL.3 fixture, simply connect it to an appropriately-rated power source.
Homing the Fixture
When the DL.3 fixture is connected to an appropriately-rated power source, it automatically
begins a homing procedure to verify that the major functions of the fixture and its internal
projector are oriented properly.
Shortcut: Holding down the inner most (i.e. middle) two menu tab buttons for
more than two seconds will home the unit.
The DL.3 Menu Display Panel
The DL.3 display panel gives access to the fixture’s onboard menu system. Chapter 3: The
Digital Light Menu System describes the menu system configuration options in detail.
NOTE: Most configuration features are also available through the Content Management
Application (CMA), (see
Viewing Server Configuration on page 278.)
WARNING:
This equipment is designed for connection to a branch circuit
havi
ng a maximum overload protection of 20 A.
CAUTION:
Do not power on the fixture until ve
rifying that the line cord
cap is suitable for the power source in your location. For more
information, see Attaching a Power Cord Cap on page
9.
Disengage Pan and Tilt locks befor
e operating the fixture. For
more information, see Pan and Tilt Locking o
n page 9.
CAUTION:
Always isolate DL.3 fixtures from generators with a UPS or
go
od quality power conditioner to prevent damage occurring to
the integrated media server and projector housed in the DL.3
from generator drop-outs, and sharp voltage and frequency
fluctuations.
