CHAPTER 14
Fixture Motion Functions
DL.3 Digital Light User Manual 243
Projector Control
Control Parameter Projector Options
These Control parameter options remotely access and operate the internal projector’s menu
system
.
Control Option Description
Displays the Projector’s internal Menu System
Projector Up arrow
NOTE: These options control the directional buttons
on the projector menu display and cannot
be activated until you set the Dimmer
parameter to 0.
Projector Down arrow
Projector Left arrow
Projector Right arrow
Store Menu selection
The following options are always active and do not require the dimmer to be at zero
Projector Floor Orientation
These commands activate the projector
’s setting for specific mounting
or projection alternatives.
Once set, these commands maintain their value until reset even after
shut
down and re-homing. For example, if the Control parameter is set to
switch the unit to Ceiling orientation, then the unit will remain in Ceiling
orientation until another command is sent to switch back to Floor. This
allows the Control parameter to revert to another value without losing
the orientation or mirroring status.
Projector Ceiling Orientation
Projector Front Projection
Projector Rear Projection
Input from External RGBHV to
Projector
Video input can be utilized with either RGBHV or VGA but not both. You
can select betw
een RGBHV and VGA in the menu system, (see
DMX_Control Screen on p
age 30). RGBHV is the factory default.
Before using DMX to change DL.3 or DL.2 inputs, you must enable the
Projec
tor Input by DMX option in the menu system (see
Set_Projector Screen on p
age 34) or through the CMA (see DL.3
and DL.2 Media Server Configuration Options on p
age 282).Once
the selection is made, allow about 10 seconds for the change to take
ef
fect.
Graphics Engine to Projector
Input from S-Video In (camera
to Ca
mera Out) to Graphics
Engine
Input from Camera to
Graphics Engine (default)
The following options require the dimmer to be at zero
Lens Shift Engaged
Mechanically offsets the projector lens 107%
vertically (available for
DL.3 fixtures only).
Lens Shift Off
Centers the image on the fixture (available for DL.3 fixtures only).
The following options do not require the dimmer to be at zero
SDI Output mode
Routes the internal camera feed to the SDI card for output to another
DL.
3 fixture for projection after the Input from Camera to Graphics
Engine has been selected.
SDI Input mode Routes the SDI input to the capture card.
CAUTION:
Do not physically connect both the VGA and the RGBHV connectors at the
same time
. Doing so can damage the projector and void the warranty.
