DL.3 Digital Light User Manual 321
Appendix A:
DMX Protocol
DL.3 and DL.2 Digital Lights, and Axon Media Servers utilize the same DMX protocol
with the following variations:
• DL.3 and DL.2 fixtures include channels for moti
on and camera control
• DL.2 and original Axon media servers allow a
maximum of four Graphic Objects
instead of nine
The following tables list the parameters and their associated DMX channel number(s). The
r
ange for a server on the DMX link depends on the number of Graphic Objects you select for
your application. For more detailed information on DMX Protocol, please contact customer
support at High End Systems.
NOTE: Gray shaded parameters are not available in Version 1 Protocol
DL.3 and DL.2 Version 2 DMX Channel Assignment
DL.3 and DL.2 Mechanical Control
Parameter Name DMX Chan #
Motion Functions
Pan
1
2
Tilt
3
4
Dimmer 5
Focus 6
Zoom 7
MSpeed 8
Macro 9
Control
10
Camera Functions (Not in DL.3F fixtures)
Zoom
11
12
Focus
13
14
Infrared 15
Camera Shutter 16
White Balance 17
Camera Orientation 18
Camera Effects 19
Red Gain 20
Blue Gain 21
