CHAPTER 9
Graphic Functions: Opacity and Effects
106 DL.3 Digital Light User Manual
Effect Mode Parameters
Three Effect Mode parameters are available for each individual 3-D object, each with three
Modifier parameters. Both Effect parameters have an identical list of color and visual effect
options. This lets you apply a dual-effect combination to the selected 3-D object.
NOTE: Not all modes combine effectively. For example, you cannot glow a
wobbulating object very well.
The table below describes the interaction between an Effect Mode parameter and its three
associated Modifier parameters. You can find a detailed description and example of each option
in Chapter 13: Effect Mode Options
Descriptions on page 147.
NOTE: Modifier channels for Effect Mode 1 are labeled as CMY in the
Wholehog system so you can also make use of the color picker, HSI,
and other Wholehog functions. Use the CMY parameter controls to
adjust the three Effect Mode 1 Modifier parameters for both the Global
and Graphic fixture types. The default for Effect Mode 1 is set to CMY1
as well. Effect Mode 2 and 3 Modifier channels are labeled Mod 1, Mod
2, and Mod 3.
DMX
value
Name/Description
Adjustments
Modifier 1 Modifier 2 Modifier 3
0 Safe (no effects selection) NA NA NA
1 CMY (RGB invert) Cyan Magenta Yellow
2 CMY Add, All Pixels Cyan Magenta Yellow
3 CMY Add, All Non-black Pixels Cyan Magenta Yellow
4 RGB Add, All Pixels Red Green Blue
5 RGB Add 2, All Pixels Red Green Blue
6 RGB Add, All Non-black Pixels Red Green Blue
7 RGB Swap to GBR Red to Green Green to Blue Blue to Red
8 RGB Swap to BRG Red to Blue Green to Red Blue to Green
9 Solarize 1 inverts a color value < DMX value Red Green Blue
10 Solarize 2 inverts a color if value > DMX value Red Green Blue
11 Solarize 3 sets color to 0 if value < DMX value Red Green Blue
12 Solarize 4 sets color to 0 if value > DMX value Red Green Blue
13 DotP and Resample Red Green Blue
14
Color Cycle cycles colors with DMX value
cont
rolling cycle speed.
Red Green Blue
15
All or Nothing sets color values > mod value = 255
and all oth
er color values = 0
Red Green Blue
16 Solid color RGB Red Green Blue
