CHAPTER 13
Effect Mode Options Descriptions
DL.3 Digital Light User Manual 199
Film Burn/Unburn
Effect Mode parameter DMX value = 93
This effect creates multiple burn patterns over the image.
Modifier 1: Adjust the burn-through rate. A DMX value o
f 65 begins creating a burn pattern
with flames from 64 = slowest to 127 = fasted rate. Values below 65 “unburn the pattern from
63 = slowest to 0 = fastest unburn. Values in the upper half of the range create the burn
pattern without flames from 192 = slowest to 255 = fastest burn rate. A value of 191 “unburns”
the patterns from 191 = slowest to 128 = fastest “unburn” without flames.
Modifier 2: Adjusts the amount of film blackening around t
he burn areas from 0 = the smallest
amount of blackening to 255 (100%) = the largest blackened area.
Modifier 3: Each DMX value selects one of 255 burn patterns.
Object Effect Global Effect
Original Content
Modifier 1 parameter DMX = 152
Modifier 2 parameter DMX = 234
Modifier 3 parameter DMX = 211
