APPENDIX D
360
Electrical
Input ratings: 100–120V 7.0A maximum 50/60Hz, 200–240V 3.5 A 50/60Hz
Power factor: 0.94
Fuse: Power supply output fuse: 5 A, 250 V slow blow only.
Lamp: 330W NSH
Light Output: 7000 ANSI lumens
Rated Lamp Life: 2000 hours
Computer
Processor: Intel Core2Quad Q9550
Memory: 2 GB DDR2 RAM
Hard drive: 750 GB Seagate SATA
Video Card: ATI Radeon HD4850
SDI Capture Card: Decklink SDI – High Definition (no
t included in DL.3F model)
Operating System: Windows XP embedded
NOTE: Some earlier versions of DL.3 media servers may have a different
hardware configuration. Find the hardware configuration listed by
serial number at the DL.3 support page of the High End System
website (
www.highend.com/support/digital_lighting).
Projector
Model: Sanyo PCL-XP200L
Aspect ratio: 4:3 native
Brightness uniformity: 90%
Contrast ratio: 2200:1, full on/full off
Display technology: 1.3” TFT 3 Poly-5: x3/Color Control x1
Panel resolution: 1024 x 768 dots
Zoom Lens Throw Ratio: 1.8–2.4:1 (standard)
Long Zoom Lens Throw Ratio: 2.4–4.3:1 (optional accessory)
Ultra Long Zoom Lens Throw Ratio: 4.3–6.0:1 (optional accessory)
Wide Angle Zoom Lens Throw Ratio: 1.3–1.8:1 (optional accessory)
WARNING!
Class 1 equipment – This equ
ipment must be earthed.
