High End Systems DL.3 - Texture Ripple, Horizontal; Texture Ripple, Vertical

CHAPTER 13
Effect Mode Options Descriptions
DL.3 Digital Light User Manual 235
Texture Ripple, Horizontal
Effect Mode parameter DMX value = 22
This effect varies the distance of reference points to the applied media file texture around the
X axis without affecting the underlying object.
Modifier 1: Adjusts the size (amplitude) of the ripple
from 0 = no adjustment to 255 (100%) =
maximum size.
Modifier 2: Adjusts the rate (frequency) of the ripple
from 0 = no adjustment to 255 (100%) =
maximum rate.
Modifier 3: Adjusts the offset (phase) speed and direct
ion. A DMX value of 128 (50%) = no
adjustment. DMX Values above the midpoint increase speed in a forward direction to 255
(100%) = fastest speed. DMX values below the midpoint increase speed in a backward direction
from no adjustment to 0 = fastest speed.
Texture Ripple, Vertical
Effect Mode parameter DMX value = 23
This effect varies the distance of reference points to the applied media file texture around the
Y axis without affecting th
e underlying object.
Modifier 1: Adjusts the size (amplitude) of the ripple
from 0 = no adjustment to 255 (100%) =
maximum size.
Modifier 2: Adjusts the rate (frequency) of the ripple
from 0 = no adjustment to 255 (100%) =
maximum rate
Modifier 3: Adjusts the offset (phase) speed and direct
ion. A DMX value of 128 (50%) = no
adjustment. DMX Values above the midpoint increase speed in a forward direction to 255
(100%) = fastest speed. DMX values below the midpoint increase speed in a backward direction
from no adjustment to 0 = fastest speed.
Object Effect Global Effect
Object Effect Global Effect
