CHAPTER 13
Effect Mode Options Descriptions
184 DL.3 Digital Light User Manual
Transparent Color, Invert
These effects remove a color (or small color range) from one graphic image to reveal another
“behind” it. The removed color becomes transparent. The modifier parameters define the color
you want to select as the transparent color in terms of Red, Green and Blue values. An Inverted
Transparent Color effect selects a color range either side of the defined value and then sets
every other color as transparent.
Modifier 1: Defines the red color component from 0 = no re
d to 255 (100%) = maximum red
saturation.
Modifier 2: Defines the green color component from 0 = no green to 255 (100%) = maximum
green satu
ration.
Modifier 3: Defines the blue color component from 0 = no blue to 255 (100%) = maximum
blue satu
ration.
Transparent Color Invert, Coarse
Effect Mode parameter DMX value = 31
The Transparent Color Invert, Coarse effect selects a color range ±40% either side of the
defined value.
Transparent Color Invert, Medium
Effect Mode parameter DMX value = 30
The Transparent Color Invert, Medium effect selects a color range ±25% either side of the
defined value.
Transparent Color Invert, Fine
Effect Mode parameter DMX value = 29
The Transparent Color Invert, Fine effect selects a color range ±15% either side of the defined
value.
Object Effect Global Effect
