High End Systems DL.3 - Page 147

CHAPTER 11
Global Functions
DL.3 Digital Light User Manual 121
140
Curve Correction, Inside Sphere corrects shape
projecting
on a sphere’s inside surface
Adjusts
Corr
ection
Sets Vertical
Center
Sets Horizontal
Center
141
Enhanced Collage Generator provides higher
resolution
for collage arrays larger than 4 x 4.
Selects Array
Ty
pe
Selects array
cell to display
Adjusts Edge
blending
142
Spherical Mapping, Outside maps output to a
portion of a
sphere’s outside surface.
Sets Longitude
An
gle
Sets Latitude
Angle
Sets Latitude
Center
143
Spherical Mapping, Inside maps output to a
portion of a
sphere’s inside surface.
Sets Longitude
An
gle
Sets Latitude
Angle
Sets Latitude
Center
144 Mattes apply provided mattes over image Matte Effect Matte Pattern Texture Source
145
Collage Generator Wrap adds right and left edge
ble
nding for 360 degree panoramas
Selects Array
Ty
pe
Selects array
cell to display
Adjusts Edge
blending
146
Segmented Collage Generator accepts user
defined port
ion of content for each cell in the grid
Selects Array
Ty
pe
Selects array
cell to display
Adjusts Edge
blending
147
Segmented Collage Generator Wrap adds right
and lef
t edge blending to the user defined cell
content for 360° panoramas
Selects Array
Ty
pe
Selects array
cell to display
Adjusts Edge
blending
148
Curved Surface, Horizontal Convex Cylinder
corrects shape projecting on curved surface
Adjusts
Corr
ection
Sets Horizontal
Center
Not Used
149
Curved Surface, Horizontal Concave Cylinder
cor
rects shape projecting on curved surface
Adjusts
Corr
ection
Sets Horizontal
Center
Not Used
150
Collage Gen 3 provides, updated blend curves for
lar
ge collage arrays
Selects Array
Ty
pe
Selects array
cell to display
Adjusts Edge
blending
151
Collage Gen 3 Wrap provides updated right and
lef
t blend curves for 360° panoramas
Selects Array
Ty
pe
Selects array
cell to display
Adjusts Edge
blending
152
Segmented Collage Gen 3, improved blending
ove
r global effect 146.
Selects Array
Ty
pe
Selects array
cell to display
Adjusts Edge
blending
153
Segmented Collage Gen 3 Wrap, improves edge
ble
nding over global effect 147.
Selects Array
Ty
pe
Selects array
cell to display
Adjusts Edge
blending
223
Modifier used with global sphe
rical mapping effect
142. Defaults to 0 otherwise.
NA NA NA
224
Modifier used with global sphe
rical mapping effect
142. Defaults to 0 otherwise.
NA NA NA
255
Pan and Scale zooms in and pans across a
still image
Horizontal
position
Vertical
po
sition
Zoom in
and out
DMX
Va
lue
Effect Mode Name/Description
Adjustments
Modifier 1 Modifier 2 Modifier 3
