CHAPTER 13
Effect Mode Options Descriptions
204 DL.3 Digital Light User Manual
Modifier 1: This parameter allows you to select from three framing modes.
Modifier 2: When the Modifier 1 DMX value = 0 or 1, this
channel selects from profiles that
vary in gradient density or pattern. When Modifier 1 DMX value = 2, this Modifier is not used.
Modifier 3: When Modifier 1 DMX Value = 1, this par
ameter determines how to use the
rendered Graphic Object content as a texture for the frame.When Modifier 1 DMX value = 2, this
Modifier is not used.
DMX
Value
Action
0
Frames the image using an Internal Frame profile to control the Global Fade Edge parameter
appeara
nce.
1
Frames the image using an Internal Frame profile to control the Global Fade Edge parameter
appeara
nce. Rendered Graphic Object content is selected at Frame texture using Modifier 3
parameter
2
Image clipping changing operation of the Global Image Edge
Fade parameters to Emulate Framing
Shutters
Modifier 1
DMX Value
Modifier 3
DMX
valu
e
Action
0
NA
Not Used
1
0
Graphic Object 1 texture without applied Effects
1
Graphic Object 1 texture including its first applied Effect
2
Graphic Object 1 texture including its first two applied Effects
3
Graphic Object 1 texture including its first three applied Effects
10
Graphic Object 2 texture without applied Effects
11
Graphic Object 2 texture including its first applied Effect
12
Graphic Object 2 texture including its first two applied Effects
13
Graphic Object 2 texture including its first three applied Effects
20
Graphic Object 3 texture without applied Effects
21
Graphic Object 3 texture including its first applied Effect
22
Graphic Object 3 texture including its first two applied Effects
23
Graphic Object 3 texture including its first three applied Effects
2
NA
Not Used
