APPENDIX A
DMX Protocol
DL.3 Digital Light User Manual 327
Control
Function
(To prevent
inadvertent
triggering,
some Control
Function op-
tions will not
activate until
the value has
been held for a
period of time.
A number in
p
arenthesis is
the minimum
number of
consecutive
times a DMX
value must be
received from
a controller
before the
operation
begins.)
Reserved 131-144
0 0
Graphics System Reset (80) 145-149
Camera Reset 150-155
Home Pan/Tilt (20) 160-168
Reserved 169
Home Focus/Zoom/Iris (20) 170-178
Reserved
179
Using the Projector’s Menu System
Projector Menu 180-184
NA
Projector Up arrow 185-188
Projector Down arrow 189-192
Projector Left arrow 193-196
Projector Right arrow 197-200
Store menu selection 201-204
Projector Floor Orientation 205-208
Projector Ceiling Orientation 209-212
Projector Front Projection 213-216
Projector Rear Projection
217-220
Changing Projector Inputs (Set Dimmer Channel = 0)
External RGBHV to Projector 221-224
NA
Graphics Engine to Projector (default)
225-228
Changing Graphics Engine Inputs (Set Dimmer Channel = 0)
S-Video In to Graphic Engine, Internal Camera to
Camera Out
229-232
NA
Internal Camera to Graphics Engine (default)
233-236
Setting Projector Lens Shift (Set Dimmer Channel = 0)
Available only in DL.3 and DL.3F fixtures.
Lens Shift Engaged (100) 237-240
NA
Lens Shift Off (100)
241-244
Setting SDI Switching Mode Available only in DL.3 fixtures.
Camera Routed to SDI Output (100) 245-248
NA
SDI Input Routed to Capture Card (100) 249-252
Reserved 253-255
99-100
Parameter Description
DMX Value Default
Dec. % Dec. %
