XL8 Control Centre
Operator Manual
Chapter 10:Advanced Operation
This chapter details the advanced operating procedures for the XL8 Control Centre.
Please note that this chapter does not describe every operation, as some are very
simple and can be completed, for example, just by the press of a button. In such cases
the information you are looking for will probably be found in the bay description
chapters, that is, Chapter 4 “Input Bays”, Chapter 5 “Mix Bay” and Chapter 6 “Output
Bay”.
Mixer details
Refer to “Setting up a mix” on page 185.
Mixing (buses)
The primary buses are shown in the following table.
Table 4: Definition of primary buses
Bus Description and Option Source and
Destination
Aux pairs 2 x mono auxes (contributions taken
pre-/post-fader)
1 x stereo aux (contributions taken
pre-/post-fader with own level and pan)
2 x mono mix groups (contributions taken
post-fader)
1 x stereo mix group (contribution taken
post-fader and pan)
2 x mono mix minus (contributions taken
post-fader)
1 x stereo mix minus (contributions taken
post-fader and pan)
From inputs to aux buses
in the mix area
Matrix pairs 2 x mono matrix (contributions taken
pre-/post-fader with own level controls)
1 x stereo matrix (contributions taken
pre-/post-fader with own level and pan)
From inputs and aux
buses to matrix outputs
Master Mono master (contribution has own level
control)
Stereo master (contributions taken post-fader
and pan)
If sending to masters in SIS, contribution is
taken post-pan image control, and the centre
goes to the mono master
From inputs and aux
buses to master outputs
Stereo solo bus
(A or B)
PFL stereo (or spread centre-panned mono)
AFL stereo (or spread centre-panned mono)
From anywhere to the
monitor outputs
