18 Chapter 2: XL8 Live Performance System Overview
XL8 Control Centre
Operator Manual
Each of the 16 auxiliary inputs has:
• Input gain.
• Source from internal FX or external pool input.
•Fader.
•Panpot (SIS™).
• Routing via level controls to the 16 matrix buses.
• Routing via pan control to the left, right and mono master buses.
Mix channel processing
Each of the 32 auxiliary mix buses has:
• Subgroup, auxiliary or mix minus modes.
• Dual mono or stereo pair modes.
• Six-band PEQ.
• Optional 31-band GEQ (replaces PEQ).
• Frequency-conscious compressor with soft clip limiter and choice of five compression
styles.
• Insert point.
• Routing via level controls to the 16 matrix buses.
• Routing via pan control to the left, right and mono master buses.
• Direct input.
Each of the 16 matrix buses has:
• Six-band PEQ.
• Optional 31-band GEQ (replaces PEQ).
• Five-mode frequency-conscious compressor with soft clip limiter and external side
chain.
• Insert point.
• Direct input.
Each of the master output buses has:
• Six-band PEQ.
• Optional 31-band GEQ (replaces PEQ).
• Five-mode frequency-conscious compressor with soft clip limiter and external side
chain.
• Insert point.
• Direct input.
