82 Chapter 5: Mix Bay

XL8 Control Centre

Operator Manual

Faders and masters

The principles of operation of the masters section is basically the same as for the

equivalent section on each of the input strips, see page 61.

1

2

6

3

4

5

9

8

7

Press this quick access

button to select the

masters section and

faders to the control

surface
