301
XL8 Control Surface
Operator Manual
DL451 I/O - analogue inputs
DL451 I/O - analogue outputs
DL451 I/O - digital inputs
DL451 I/O - digital outputs
DL451 I/O - MIDI and GPIO
DL451 I/O - digital system inputs and outputs
Connector 3-pin XLR balanced
A/D converter 24-bit, 96k and 128 times over sampling
Connector 3-pin XLR balanced
D/A converter 24-bit, 96k and 128 times over sampling
Connector AES3 (two channels of digital audio) on 3-pin
XLR
Sample rates Accepts any frequency between 32k to 96k
Bypass Sample rate converter can be bypassed
Connector AES3 (two channels of digital audio) on 3-pin
XLR
Sample rates 48k, 96k or auto tracking to inputs
Bypass Sample rate converter can be bypassed
Word length 16-, 20- or 24-bit
MIDI connector In, out and through on 5-pin DIN
GPIO IN connector 25-pin D-type (opto isolated)
GPIO OUT connector 25-pin D-type (opto isolated)
System connector AES50 (24 channels of bi-directional digital
audio) on Ethercon XLR
Duplicate connector AES50 (24 channels of bi-directional digital
audio) on Ethercon XLR providing dual
redundant back up of channels
