140 Chapter 7: GUI Menu Options
XL8 Control Centre
Operator Manual
General screen
home Preferences General
The General screen provides a number configuration features, such as, GUI remapping,
LCD adjustment etc., and provides useful system and console information.
1 Bay Select section shows which bay the
GUI you are currently using is mapped to.
2 Host software version information section.
Provides the current host software version of
the network equipment, includes the GUI’s
current build version.
3 Delay Compensation section allows you
to select/deselect delay compensation for
parameters such as input channel insert.
4 Meter Preferences section allows you to
the time for meter parameters, such as decay
and attack, and also to switch them on or off.
5 Screen brightness allows you to adjust
the brightness of the GUI screen.
6 Screen contrast allows you to adjust the
contrast of the GUI screen.
7 inf button allows you to set the DSP
timeout to infinity, that is, no timeout.
8 This control knob allows you adjust the
DSP timeout to between 10 and 600 seconds.
1
4
23
5
6
8
7
