Midas XL8

299
XL8 Control Surface
Operator Manual
Mixing noise (all bus types) 22Hz to 22kHz unweighted
Signal path noise 22Hz to 22kHz unweighted (inputs 150R terminated)
Dynamic range 22Hz to 22kHz unweighted
No. of Inputs Gain Fader
Position
Pan Output Noise
12 0dB
-infinity (-4)
Central -91dBu
12 0dB 0dB Central -84dBu
24 0dB
-infinity (-
4)
Central -91dBu
24 0dB 0dB Central -81dBu
48 0dB
-infinity (-
4)
Central -91dBu
48 0dB 0dB Central -78dBu
96 0dB
-infinity (-
4)
Central -91dBu
96 0dB 0dB Central -75dBu
Input Output Gain Output Noise EIN
DL431 splitter DL431 splitter A out 0dB -98dBu -98dBu
DL431 splitter DL431 splitter A out 40dB -88dBu -128dBu
DL431 splitter DL431 splitter B out 0dB -98dBu -98dBu
DL431 splitter DL431 splitter B out 40dB -88dBu -128dBu
DL431 splitter DL431 splitter C out -6dB -123dBu -117dBu
DL431 splitter DL451 I/O 0dB -89dBu -89dBu
DL431 splitter DL451 I/O 40dB -87dBu -127dBu
DL451 I/O DL451 I/O 0dB -89dBu -89dBu
DL451 I/O DL451 I/O 40dB -87dBu -127dBu
Input Output Gain Maximum
Output
Dynamic
Range
DL431 splitter DL431 splitter A out 0dB +26dBu 124dBu
DL431 splitter DL431 splitter A out 40dB +26dBu 114dBu
DL431 splitter DL431 splitter B out 0dB +26dBu 124dBu
DL431 splitter DL431 splitter B out 40dB +26dBu 114dBu
DL431 splitter DL431 splitter C out -6dB +21dBu 144dBu
DL431 splitter DL451 I/O 0dB +21dBu 110dBu
DL431 splitter DL451 I/O 40dB +21dBu 108dBu
DL451 I/O DL451 I/O 0dB +21dBu 110dBu
DL451 I/O DL451 I/O 40dB +21dBu 108dBu
