Output channel processing 19
XL8 Control Centre
Operator Manual
Output channel processing
Each of the 16 matrix buses has:
• Six-band PEQ.
• Optional 31-band GEQ (replaces PEQ).
• Five-mode frequency-conscious compressor with soft clip limiter and external side
chain.
• Insert point.
• Direct input.
Each of the three master output buses has:
• Six-band PEQ.
• Optional 31-band GEQ (replaces PEQ).
• Five-mode frequency-conscious compressor with soft clip limiter and external side
chain.
• Insert point.
• Direct input.
Effects processing and GEQs
The XL8 contains 16 mono Klark Teknik (KT) GEQs and 16 effects processors as
standard.
The 16 effects processors can be freely chosen from:
• KT DN780 reverb.
•Stereo delay.
•Stereo flanger.
•Stereo phaser.
The 16 mono KT GEQs can be patched into any output. There are many patching
options for the effects processors:
• Assign to any insert send/return.
• Assign to any pool, in or out.
• Assign FX out to aux return.
• Assign FX in to aux send (post-fade).
• Assign FX out to bus direct in.
• Assign FX in to channel direct out.
Every XL8 comes supplied with a KT DN9331 RAPIDE motorised fader GEQ controller.
This unit provides rapid adjustments of the graphics with real hardware, and not a
mouse and screen. The graphic channel is selected either by the control centre’s SOLO
button (solo tracking system (STS)) or by buttons on the RAPIDE itself.
