210 Chapter 10: Advanced Operation
XL8 Control Centre
Operator Manual
Output channels
Only adjacent output channels can be linked and these must be within the same fast
strip. Stereo linking output channels is a GUI-only function; see “To set up a stereo
aux” on page 200.
Table 7 “Linking - input channels” gives the linking status of parameters.
Table 7: Linking - input channels
Parameter Linking
48V Linked
Phase Not linked
Gain trim Not linked
Gain steps Linked
30Hz Linked
Meter check Not linked
Hi pass All controls linked
Lo pass All controls linked
EQ All controls linked
Direct mute Not linked
Direct solo Not linked
Direct B Linked
Direct level Linked
Direct assn Linked
Direct pre Linked
Safes All controls linked
Proc order Linked
Dynamic Linked
Aux levels Linked
Aux pan Not linked
Aux ON Linked
Aux pre Linked
Bus select All controls linked
Main mute Not linked
Main solo Not linked
Solo B Linked
Main pan Not linked
SIS Disabled - does not function in stereo
ST master Linked
Mono master Linked
Fader Not linked
