Auto-mute groups
The auto mute groups section has eight sets of auto-mute masters that allow you to
create mute groups. Configuration is carried out via the GUI menu; see “Mute Groups
screen” on page 135.
An auto-mute on can happen because of:
• Activating an assigned auto-mute.
• Assigning an already active auto-mute.
• Recalling a scene that assigns an already active auto-mute.
An auto-mute off can happen because of:
• Deactivating all of the assigned auto-mutes.
• Unassigning all of the active auto-mutes.
• Recalling a scene that de-assigns all of the active auto-mutes.
1 MUTE switch to mute or unmute all of the
assigned channels. Also, the same channel
can be assigned to more than one auto-mute
group - the channel should be auto-muted
while any of the mute groups to which it is
assigned are muted.
2 SELECT switch is used to program the
auto-mute channel assignment. Shows
current assignments to mute group and allows
them to be changed.
1
2
