XL8 control centre - miscellaneous inputs and outputs
Word clock IN connector BNC
Word clock OUT connector BNC
Duplicate word clock IN BNC providing dual redundant back up
Duplicate word clock OUT BNC providing dual redundant back up
AES3 sync IN connector 3-pin XLR
AES3 sync OUT connector 3-pin XLR
Duplicate AES3 sync IN 3-pin XLR providing dual redundant back up
Duplicate AES3 sync OUT 3-pin XLR providing dual redundant back up
Ethernet tunnel 1 connector Ethercon XLR
Ethernet tunnel 2 connector Ethercon XLR
Duplicate Ethernet tunnel 1 Ethercon XLR providing dual redundant back up
Duplicate Ethernet tunnel 2 Ethercon XLR providing dual redundant back up
Monitor input connector 3-row 15-pin D-type - analogue VGA
KVM input connection Screen 3-row 15-pin D-type (analogue VGA)
and USB keyboard/mouse
USB host connection
Line I/O and mic splitter
USB 2.0 full speed (12.0Mbs)
500mA maximum load
USB slave connection
Line I/O and mic splitter
USB 2.0 full speed (12.0Mbs)
USB host connection
Surface
USB 2.0 full speed (12.0Mbs)
1A maximum load
