Navigating the inputs 171
XL8 Control Centre
Operator Manual
To select an input channel via a switch or button
To change selection of an input channel within an input bay you can (provided input
channel is already displayed):
a) Press the LCD switch of the input channel you require.
b) Scroll by one channel at a time. You can scroll through all of the banks,
encompassing the entire 96 inputs. Channels 1 and 96 are treated as adjacent
channels (although they are in separate banks).
c) Press a quick access button on input channel you require.
When the new channel is selected to the GUI, the controls that were last used, that is,
preamp, EQ, DYN or mixes, are displayed.
Press the LCD switch of the required input
channel. Its display will change to a
‘negative’ image (shown below) to show it
is selected.
a)
b)
Scrolls one channel
to the left
Scrolls one channel
to the right
c)
You stay on the same GUI screen, but
scroll to the next bank
See “To select a channel section to the
GUI’s channel strip” on page 173.
