Midas XL8

Monitoring 113
XL8 Control Surface
Operator Manual
source and output (a and b)
source a and source b sections contain monitor input selector switches. On both A
and B systems, these define the source for the monitor section from the possible
‘primary’ choice of stereo master (ST), mono master (MONO) or external (EXT).
Additionally, there are talk back A and B switches.
The monitor outputs, output a and output b, have some common control types for A
and B; see “Monitors” on page 202.
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9
