Midas XL8

256 Chapter 13: Effects
XL8 Control Surface
Operator Manual
Flanger effects
The flanger effect consists of one or, if configured as stereo, two-tap delay lines. One
tap is fixed and the other tap position is modulated to provide ‘thru-zero’ flanging or
single tap modulation when ‘thru-zero’ is off.
1 Front panel; see “Front panel” on
page 259.
2 Rear panel; see “Rear panel - common” on
page 261.
3 See “Front panel - common element” on
page 260.
4 See “Front panel - common element” on
page 260.
5 See “Front panel - common element” on
page 260.
1
2
3
4
5
