Miscellaneous digital characteristics
Type I/O Description Notes Connector
Word clock IN Accepts TTL level, 96kHz square
wave; impedance 75 Ohms
BNC
Word clock OUT Provides a TTL level, 96kHz
square wave
BNC
AES sync IN Accepts a 96kHz digital audio
signal conforming to AES3 - 2003
XLR
AES sync OUT Provides a 96kHz grade II
reference signal conforming to
AES3 - 2003
XLR
Ethernet tunnel - Car5, Auto MDIX, 00Mbs Fast
Ethernet physical layer
Ethercon XLR
