128 Chapter 7: GUI Menu Options

XL8 Control Centre

Operator Manual

Aux Returns 1-16 (mix channels) screen

The Aux Returns 1-16 screen shows all of the controls for the returns; see “Returns” on

page 84.

Aux Sends 1 - 16 (mix channels) screen

There are two Aux Sends screens that encompass the 32 auxes, each in banks of 16

channels. The Aux Sends 1 - 16 screen shows all of the controls for the auxes

channels; see “Auxes” on page 73.
