Side chain 65
XL8 Control Surface
Operator Manual
Select Side-Chain Source window
6
1
7
2
3
4
5
1 1. Source From Channel of Type... panel
gives you options from which to select the side chain
source.
2 2. Choose Channel Number... panel gives you
the available channels of your chosen channel type.
Select which one you want.
3 3. Choose Pick-Off Point... panel gives you
available pick-off points from which to choose where
the side chain will exit from.
4 CANCEL button exits the window without
selecting the side chain source.
5 OK button selects the side chain source, as
chosen in the three panels, and exits the window.
6 Side-Chain Source for: field shows which
input channel you are selecting the source of the side
chain for.
7 Device: field shows the current side chain
source device for the selected input channel.
