296 Appendix B: Technical Specification
XL8 Control Surface
Operator Manual
XL8 general specifications
Sampling frequency 96kHz
Latency delay <2ms input to master (no compensation)
Dynamic range 110dB, 22Hz to 22kHz (no pre-emphasis)
Maximum voltage gain 85dB inputs to subgroups and masters
91dB inputs to aux and matrix
Crosstalk at 1kHz -100dB physically adjacent input channels
Crosstalk at 10kHz -100dB physically adjacent input channels
Fader/pan cut off at 1kHz -100dB
Fader/pan cut off at 10kHz -100dB
Display screens 5 x 15” daylight-viewable colour screens
LCD switch 70 x RGB colour
Motorised faders 71 x touch-sensitive (+31 on GEQ Rapide)
Fader resolution 1024 steps
Encoders 258 touch-sensitive
Encoder resolution 512 steps
Dimensions XL8 control centre: 1875 x 1054 x 421 mm
DL431 splitter: 6U x 410 mm deep
DL451 I/O: 3U x 410 mm deep
DL461 router: 3U x 410 mm deep
DL471 DSP: 1U x 410 mm deep
Net weight (standard install) Control centre: 160 kg
4 x DL431: 86 kg
5 x DL451: 63 kg
2 x DL461: 23 kg
10 x DL471: 67 kg
Total: 399 kg
Power requirements 100V to 240V, 50 to 60Hz
Operating temperature range +5°C to +40°C
Storage temperature range -20°C to +60°C
