148 Chapter 8: Connections, Setting Up And Powering Up

XL8 Control Centre

Operator Manual

Rear panel connections

The rear of the XL8 Control Centre contains the monitor connector panels.

1 Five monitor connector panels; see

page 149.

2 KVM, monitor and synchronisation

onnector panel; see page 150.

3 System interconnection panel; see

page 151.

4 Power supply panel; see page 152.
