Master controls and fader 61
XL8 Control Surface
Operator Manual
Master controls and fader
masters section provides three routing switches to the master buses with pan control.
Pan provides master panning as three-way or two-way and also provides two-way
panning for any stereo mix groups. (When used for monitor applications, aux, mix and
main buses are controlled from the channel master pan and fader. AFL solos also
operate as a default from the main solo switch.)
Solo routing section (above fader) activates solo routing and selects which monitor
section (A or B) signals are routed to.
1
2
3
4
5
6
9
8
7
14
10
13
12
11
