298 Appendix B: Technical Specification
XL8 Control Surface
Operator Manual
Input CMRR
Distortion at 0dBu
Distortion at +20dBu
Input Output Gain 100Hz 1kHz
DL431 splitter DL431 splitter A out 0dB 80dB 80dB
DL431 splitter DL431 splitter A out 40dB 90dB 90dB
DL431 splitter DL431 splitter B out 0dB 80dB 80dB
DL431 splitter DL431 splitter B out 40dB 90dB 90dB
DL431 splitter DL431 splitter C out -6dB 110dB 90dB
DL431 splitter DL451 I/O 0dB 80dB 80dB
DL431 splitter DL451 I/O 40dB 90dB 90dB
DL451 I/O DL451 I/O 0dB 80dB 80dB
DL451 I/O DL451 I/O 40dB 90dB 90dB
Input Output Gain 1kHz 10kHz
DL431 splitter DL431 splitter A out 0dB 0.01% 0.01%
DL431 splitter DL431 splitter A out 40dB 0.03% 0.03%
DL431 splitter DL431 splitter B out 0dB 0.01% 0.01%
DL431 splitter DL431 splitter B out 40dB 0.03% 0.03%
DL431 splitter DL431 splitter C out -6dB 0.01% 0.01%
DL431 splitter DL451 I/O 0dB 0.01% 0.01%
DL431 splitter DL451 I/O 40dB 0.03% 0.03%
DL451 I/O DL451 I/O 0dB 0.01% 0.01%
DL451 I/O DL451 I/O 40dB 0.03% 0.03%
Input Output Gain 1kHz 10kHz
DL431 splitter DL431 splitter A out 0dB 0.03% 0.03%
DL431 splitter DL431 splitter A out 40dB 0.03% 0.03%
DL431 splitter DL431 splitter B out 0dB 0.03% 0.03%
DL431 splitter DL431 splitter B out 40dB 0.03% 0.03%
DL431 splitter DL431 splitter C out -6dB 0.03% 0.03%
DL431 splitter DL451 I/O 0dB 0.03% 0.03%
DL431 splitter DL451 I/O 40dB 0.03% 0.03%
DL451 I/O DL451 I/O 0dB 0.03% 0.03%
DL451 I/O DL451 I/O 40dB 0.03% 0.03%
