303
XL8 Control Surface
Operator Manual
XL8 control centre - analogue audio system outputs
XL8 control centre - digital audio system inputs and outputs
XL8 control centre - control data system inputs and outputs
Monitor connector 3-pin XLR balanced
Talk connector 3-pin XLR balanced
Intercom connector 3-pin XLR balanced
Headset connector 5-pin XLR (stereo)
Headphone connector 1/4” jack (stereo)
Meters (39-off) 20-segment -36dBu to +21dBu
System connector AES50 (24 channels of bi-directional digital
audio) on Ethercon XLR
Duplicate connector AES50 (24 channels of bi-directional digital
audio) on Ethercon XLR providing dual
redundant back up of channels
Snake connector (copper) Sony HyperMac (192 channels of bi-directional
digital audio) on Ethercon XLR
Snake connector (fibre) Sony HyperMac (192 channels of bi-directional
digital audio) on Opticon XLR
System connector Ethercon XLR
Duplicate connector Ethercon XLR providing dual redundant back up
