302 Appendix B: Technical Specification
XL8 Control Surface
Operator Manual
DL461 router - digital audio system inputs and outputs
DL461 router - control data system inputs and outputs
DL461 router - miscellaneous inputs and outputs
XL8 control centre - analogue audio system inputs
System connector AES50 (24 channels of bi-directional digital
audio) on Ethercon XLR
Duplicate connector AES50 (24 channels of bi-directional digital
audio) on Ethercon XLR providing dual
redundant back up of channels
Snake connector (copper) Sony HyperMac (192 channels of bi-directional
digital audio) on Ethercon XLR
Snake connector (fibre) Sony HyperMac (192 channels of bi-directional
digital audio) on Opticon XLR
System connector Ethercon XLR
Duplicate connector Ethercon XLR providing dual redundant back up
Word clock IN connector BNC
Word clock OUT connector BNC
AES3 sync IN connector 3-pin XLR
AES3 sync OUT connector 3-pin XLR
Ethernet tunnel 1 connector Ethercon XLR
Ethernet tunnel 2 connector Ethercon XLR
Expansion Ethernet connector Ethercon XLR
Expansion Gigabit connector Ethercon XLR
Monitor connector 3-pin XLR balanced
Intercom connector 3-pin XLR dual channel (bi-directional) RTS
Talk connector 3-pin XLR balanced with 48V phantom
Meters (24-off) 20-segment, -36dBu to +21dBu
