Delay effects
The delay effect provides simple delay line based effects. Delay times can be specified
manually or by means of a ‘tempo-tap’ button. Three-mode delay algorithm: single -
one delay tap (mono or stereo processing); dual - two delay lines (stereo inset only);
and ping-pong - two delay lines with cross feedback.
1 Front panel; see “Front panel” on
page 255.
2 Rear panel; see “Rear panel - common” on
page 261.
3 See “Front panel - common element” on
page 260.
4 See “Front panel - common element” on
page 260.
5 See “Front panel - common element” on
page 260.
6 Left input: left delay.
7 Right input: right delay.
1
2
3
4
5
6
7
