130 Chapter 7: GUI Menu Options

XL8 Control Centre

Operator Manual

Dashboard screen

The dashboard screen shows all meters all of the time. Refer to “Mix bay GUI” on

page 69.

1 Meters section contains all of the control centre’s

level meters, that is, 96 Input Channels, 16 Aux

Returns (returns), 32 Aux Sends (auxes), three

Masters (L, R and M), Mon A and Mon B (A and B

monitors - stereo L and R) and 16 Matrix Outs.

2 Three ‘virtual’ analogue meters give signal level

indication.

3 GUI channel strip.

4 Screen swap button for switching to the output

channel display screen.
