Midas XL8

305
XL8 Control Surface
Operator Manual
XL8 input and output characteristics
Analogue input characteristics
Analogue output characteristics
Digital I/O characteristics
Input Type Load Z Gain Max. Level Connector
DL431 splitter 5K -22.5dB to +65dB +24dBu XLR
DL451 I/O 10K -25dB to +60dB +26dBu XLR
Talk mic 600R +15dB to +60dB +6dBu XLR
Headset mic 375R +60dB 0dBu XLR (5-pin)
Monitor 10K 0dB +24dBu XLR
Output Type Source Z Gain Max. Level Connector
DL431 splitter
Main
150R 0dB +24dBu XLR
DL431 splitter
Isolated
75R -6dB +18dBu XLR
DL451 I/O 50R 0dB +21dBu XLR
Talk 50R 0dB +24dBu XLR
Monitor 50R 0dB +24dBu XLR
Headphones 10R +10dB 750mW 1/4” jack
Headset 10R +10dB 750mW XLR (5-pin)
Type Chan. Data
Length
I/O Description Notes Conn.
AES3 2 24-bit Input Conforms to
AES3 - 2003
XLR
AES3 2 24-bit Output Conforms to
AES3 - 2003
XLR
AES50 24 24-bit Bi-
directional
Conform s to
AES50 -2006
Ethercon
XLR
HyperMac 192 24-bit Bi-
directional
Cat6, Gigabit
Ethernet physical
layer
Ethercon
XLR
HyperMac 192 24-bit Bi-
directional
850 nm, laser
module 1.25Gb/s
1000 base-SX
physical layer on
50/125 multimode
fibre
Opticon
XLR
