Midas XL8

Monitoring 115
XL8 Control Surface
Operator Manual
afl, pfl and talk back
1 pfl level control knob adjusts the pre-fader level.
Ranges from infinity (∞) to +10dB. PFL audio bus may
accept injected external signals.
2 afl level control knob adjusts the after-fader
level. Ranges from infinity (∞) to +10dB. AFL audio
bus may accept injected external signals.
3 talk back control knob adjusts the talk back
level. Ranges from infinity (∞) to +10dB.
1
1
2
3
3
1
2
