Scenes (automation) 193
XL8 Control Centre
Operator Manual
To store a scene
Scenes can be managed using a combination of the automation section (output bay) on
the control surface and GUI screen, or via GUI screen only. The buttons in the
automation section illuminate to show that they are active.
1 Click STORE.
2 In the new “Store” window, use the output bay’s trackball to place GUI screen’s cursor over the name
field. Press the trackball’s select button to enter the name field. Type in new scene name via the
keyboard.
3 Below new scene name, select one of the following options by clicking on it (emboldened options are
enabled, while greyed out ones are disabled):
“Insert before scene”
“Store to empty scene”
“Store to next scene”
“Overwrite scene”
4 You can use the keyboard to type in any useful scene information in the “Scene Notes” window, if you
wish.
5 Click OK to save the scene.
1
1
2a
2b
