Midas XL8

Virtual DN-780 effects 245
XL8 Control Surface
Operator Manual
Virtual DN-780 effects screen
1 Front panel; see “Virtual DN-780 front
panel” on page 246.
2 Rear panel; see “Rear panel - common” on
page 261.
3 See “Front panel - common element” on
page 260.
4 See “Front panel - common element” on
page 260.
5 See “Front panel - common element” on
page 260.
6 See “Front panel - common element” on
page 260.
1
2
3
4
5
6
