Midas XL8

297
XL8 Control Surface
Operator Manual
XL8 audio performance specifications
Frequency response
Gain error at 1kHz
Input Output Gain 20Hz 20kHz
DL431 splitter DL431 splitter A out 0dB 0dB to -0.5dB 0dB to -0.5dB
DL431 splitter DL431 splitter A out 40dB 0dB to -0.5dB 0dB to -0.5dB
DL431 splitter DL431 splitter B out 0dB 0dB to -0.5dB 0dB to -0.5dB
DL431 splitter DL431 splitter B out 40dB 0dB to -0.5dB 0dB to -0.5dB
DL431 splitter DL431 splitter C out -6dB 0dB to -1.0dB 0dB to -1.0dB
DL431 splitter DL451 I/O 0dB 0dB to -1.0dB 0dB to -1.0dB
DL431 splitter DL451 I/O 40dB 0dB to -1.0dB 0dB to -1.0dB
DL451 I/O DL451 I/O 0dB 0dB to -1.0dB 0dB to -1.0dB
DL451 I/O DL451 I/O 40dB 0dB to -1.0dB 0dB to -1.0dB
Input Output Gain Maximum Minimum
DL431 splitter DL431 splitter A out 0dB +0.5dB +0.5dB
DL431 splitter DL431 splitter A out 40dB +0.5dB +0.5dB
DL431 splitter DL431 splitter B out 0dB +0.5dB +0.5dB
DL431 splitter DL431 splitter B out 40dB +0.5dB +0.5dB
DL431 splitter DL431 splitter C out -6dB +1.0dB +1.0dB
DL431 splitter DL451 I/O 0dB +1.0dB +1.0dB
DL431 splitter DL451 I/O 40dB +1.0dB +1.0dB
DL451 I/O DL451 I/O 0dB +1.0dB +1.0dB
DL451 I/O DL451 I/O 40dB +1.0dB +1.0dB
