134 Chapter 7: GUI Menu Options
XL8 Control Centre
Operator Manual
VCA Groups screen
The VCA Groups screen provides VCA and POP management and control; see “VCA/POP
groups” on page 92. (This screen is also accessible via the control knob icons on Group
Sheet screen; see “Group Sheet screen” on page 133.)
1 POP group ID (fixed) and user-configured name
of POP group.
2 unfold button unfolds (selects) the members of
its VCA group to the input bays.
3 area B button selects monitor area B.
4 VCA group ID (fixed) and user-configured name
of VCA group.
5 The MUTE, SOLO, MUTE and FDR safes
buttons and the fader have the same functionality as
that of their group members’, but apply to the whole
group.
6 VCA group control section related to solo routing
VCA fader sections in mix bay’s control surface, see
“VCA faders” on page 91. Active when highlighted by
yellow bounding box, as shown.
7 POP group control section related to solo routing
section in mix bay’s control surface, see “VCA faders”
on page 91. Active when highlighted by yellow
bounding box.
1
2
3
2
3
5
5
5
5
5
6
4
7
8
Clicking on this area of the
menu option brings up the VCA
Groups screen (shown below)
Clicking on one of the groups
(VCA or POP) unfolds the group
to the input bays
Please refer to “Group management”
on page 132 for details of the group
management panel
