126 Chapter 7: GUI Menu Options

XL8 Control Centre

Operator Manual

Mix & Outputs screen

The Mix & Outputs option provides access to a single output or bank of outputs, and

configuration screen containing all of the output channels.

Takes you to one of the 32 Aux Sends

(banks of eight). See page 128 for

inputs 1 - 8.

Takes you to the Output Channel

Sheet screen (page 127)

Takes you to the Aux Returns 1 - 16

screen (page 128)

Takes you to the Matrix Outputs 1 -

16 screen (page 129)

Takes you to the Master Outputs 1 -

16 screen (page 129)

Takes you to the Dashboard screen (page 130)
