310 Appendix B: Technical Specification
XL8 Control Surface
Operator Manual
XL8 status functions
Meters
Screens
Screen functions
LCD switches
Splitter meters 96 x 7-LED from -18dBu to +24dBu
Control centre meters 39 x output 20-LED -36dBu to +21dBu
24 x input 20-LED -36dBu to +21dBu
48 x gain reduction 7-LED
4 x direct level meter 7-LED
Screen metering 135 x 20-segment signal level meters
192 x 7-segment gain reduction
Quantity 5 x full-colour daylight-viewable screens
Size 15” (diagonal)
Resolution 1024 x 768 pixels
External screen 5 x output connectors for remote screens
Source Each screen can be switched to source either
the local console or an external input
KVM Screen 4 can be switched to operate up to
three external computers utilising the console
trackball and keyboard
Internal GUI Advanced interpolated graphics support all
console functions
Quantity 70 x RGB colour display switches
Size 18 mm x 12 mm display area
Resolution 36 x 24 pixels
