34 Chapter 4: Input Bays
XL8 Control Surface
Operator Manual
Input signal routing
The hardware layout of each input bay, that is, the input fast zone’s eight input fast
strips and the input channel strip, has been designed to closely match the input channel
signal path. However, the signal path may vary, as there are a number of options that
enable you to alter the linear order of processing.
The diagram below shows the default signal path, on which the structure of this section
is based. This section will explain each of these groups of controls.
Input channel
signal path
Mic splitter remote controls; see page 38
Channel configuration; see page 40
Gain and filter controls; see page 44
Direct output; see page 46
Insert controls; see page 54
Compressor; see page 48
Gate; see page 52
Equaliser; see page 56
Aux controls; see page 58
Matrix controls; see page 58
Master controls; see page 61
Order can be swapped by
clicking C/O on GUI
screen; see page 43
