NXP Semiconductors LPC11U3x User Manual

UM10462 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2016. All rights reserved.
User manual Rev. 5.5 — 21 December 2016 149 of 523
NXP Semiconductors
UM10462
Chapter 8: LPC11U3x/2x/1x Pin configuration
PIO1_0/CT32B1_MAT0/
IOH_10
---1
[3]
I; PU I/O PIO1_0 — General purpose digital input/output pin.
-OCT32B1_MAT0 — Match output 0 for 32-bit timer 1.
- I/O IOH_10 — I/O Handler input/output 10.
(LPC11U37HFBD64/401 only.)
PIO1_1/CT32B1_MAT1/
IOH_11
---17
[3]
I; PU I/O PIO1_1 — General purpose digital input/output pin.
-OCT32B1_MAT1 — Match output 1 for 32-bit timer 1.
- I/O IOH_11 — I/O Handler input/output 11.
(LPC11U37HFBD64/401 only.)
PIO1_2/CT32B1_MAT2/
IOH_12
---34
[3]
I; PU I/O PIO1_2 — General purpose digital input/output pin.
-OCT32B1_MAT2 — Match output 2 for 32-bit timer 1.
- I/O IOH_12 — I/O Handler input/output 12.
(LPC11U37HFBD64/401 only.)
PIO1_3/CT32B1_MAT3/
IOH_13
---50
[3]
I; PU I/O PIO1_3 — General purpose digital input/output pin.
-OCT32B1_MAT3 — Match output 3 for 32-bit timer 1.
- I/O IOH_13 — I/O Handler input/output 13.
(LPC11U37HFBD64/401 only.)
PIO1_4/CT32B1_CAP0/
IOH_14
---16
[3]
I; PU I/O PIO1_4 — General purpose digital input/output pin.
-ICT32B1_CAP0 — Capture input 0 for 32-bit timer 1.
- I/O IOH_14 — I/O Handler input/output 14.
(LPC11U37HFBD64/401 only.)
PIO1_5/CT32B1_CAP1
/IOH_15
-H8- 32
[3]
I; PU I/O PIO1_5 — General purpose digital input/output pin.
-ICT32B1_CAP1 — Capture input 1 for 32-bit timer 1.
- I/O IOH_15 — I/O Handler input/output 15.
(LPC11U37HFBD64/401 only.)
PIO1_6/IOH_16 - - - 64
[3]
I; PU I/O PIO1_6 — General purpose digital input/output pin.
- I/O IOH_16 — I/O Handler input/output 16.
(LPC11U37HFBD64/401 only.)
PIO1_7/IOH_17 - - - 6
[3]
I; PU I/O PIO1_7 — General purpose digital input/output pin.
- I/O IOH_17 — I/O Handler input/output 17.
(LPC11U37HFBD64/401 only.)
PIO1_8/IOH_18 - - - 39
[3]
I; PU I/O PIO1_8 — General purpose digital input/output pin.
- I/O IOH_18 — I/O Handler input/output 18.
(LPC11U37HFBD64/401 only.)
PIO1_9 - - - 55
[3]
I; PU I/O PIO1_9 — General purpose digital input/output pin.
PIO1_10 - - - 12
[3]
I; PU I/O PIO1_10 — General purpose digital input/output pin.
PIO1_11 - - - 43
[3]
I; PU I/O PIO1_11 — General purpose digital input/output pin.
PIO1_12 - - - 59
[3]
I; PU I/O PIO1_12 — General purpose digital input/output pin.
Table 135. LPC11U3x pin description …continued
Symbol
Pin HVQFN33 Pin TFBGA48 Pin LQFP48 Pin LQFP64
Reset
state
[1]
Type Description
