UM10462 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2016. All rights reserved.
User manual Rev. 5.5 — 21 December 2016 316 of 523
NXP Semiconductors
UM10462
Chapter 14: LPC11U3x/2x/1x I2C-bus controller
Table 291. Slave Receiver mode
Status
Code
(STAT)
Status of the I
2
C-bus
and hardware
Application software response Next action taken by I
2
C hardware
To/From DAT To CON
STA STO SI AA
0x60 Own SLA+W has
been received; ACK
has been returned.
No DAT action or X 0 0 0 Data byte will be received and NOT ACK
will be returned.
No DAT action X 0 0 1 Data byte will be received and ACK will
be returned.
0x68 Arbitration lost in
SLA+R/W as master;
Own SLA+W has
been received, ACK
returned.
No DAT action or X 0 0 0 Data byte will be received and NOT ACK
will be returned.
No DAT action X 0 0 1 Data byte will be received and ACK will
be returned.
0x70 General call address
(0x00) has been
received; ACK has
been returned.
No DAT action or X 0 0 0 Data byte will be received and NOT ACK
will be returned.
No DAT action X 0 0 1 Data byte will be received and ACK will
be returned.
0x78 Arbitration lost in
SLA+R/W as master;
General call address
has been received,
ACK has been
returned.
No DAT action or X 0 0 0 Data byte will be received and NOT ACK
will be returned.
No DAT action X 0 0 1 Data byte will be received and ACK will
be returned.
0x80 Previously addressed
with own SLV
address; DATA has
been received; ACK
has been returned.
Read data byte or X 0 0 0 Data byte will be received and NOT ACK
will be returned.
Read data byte X 0 0 1 Data byte will be received and ACK will
be returned.
0x88 Previously addressed
with own SLA; DATA
byte has been
received; NOT ACK
has been returned.
Read data byte or 0 0 0 0 Switched to not addressed SLV mode; no
recognition of own SLA or General call
address.
Read data byte or 0 0 0 1 Switched to not addressed SLV mode;
Own SLA will be recognized; General call
address will be recognized if
ADR[0] = logic 1.
Read data byte or 1 0 0 0 Switched to not addressed SLV mode; no
recognition of own SLA or General call
address. A START condition will be
transmitted when the bus becomes free.
Read data byte 1 0 0 1 Switched to not addressed SLV mode;
Own SLA will be recognized; General call
address will be recognized if
ADR[0] = logic 1. A START condition will
be transmitted when the bus becomes
free.
0x90 Previously addressed
with General Call;
DATA byte has been
received; ACK has
been returned.
Read data byte or X 0 0 0 Data byte will be received and NOT ACK
will be returned.
Read data byte X 0 0 1 Data byte will be received and ACK will
be returned.
