UM10462 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2016. All rights reserved.
User manual Rev. 5.5 — 21 December 2016 469 of 523
NXP Semiconductors
UM10462
Chapter 24: LPC11U3x/2x/1x Appendix ARM Cortex-M0
24.4.5.1.4 Examples
The following shows two instructions that add a 64-bit integer contained in R0 and R1 to
another 64-bit integer contained in R2 and R3, and place the result in R0 and R1.
64-bit addition:
ADDS R0, R0, R2 ; add the least significant words
ADCS R1, R1, R3 ; add the most significant words with carry
Multiword values do not have to use consecutive registers. The following shows
instructions that subtract a 96-bit integer contained in R1, R2, and R3 from another
contained in R4, R5, and R6. The example stores the result in R4, R5, and R6.
96-bit subtraction:
SUBS R4, R4, R1 ; subtract the least significant words
SBCS R5, R5, R2 ; subtract the middle words with carry
SBCS R6, R6, R3 ; subtract the most significant words with carry
The following shows the RSBS instruction used to perform a 1's complement of a single
register.
Arithmetic negation:
RSBS R7, R7, #0 ; subtract R7 from zero
24.4.5.2 AND, ORR, EOR, and BIC
Logical AND, OR, Exclusive OR, and Bit Clear.
24.4.5.2.1 Syntax
ANDS {Rd,} Rn, Rm
ORRS {Rd,} Rn, Rm
EORS {Rd,} Rn, Rm
Table 429. ADC, ADD, RSB, SBC and SUB operand restrictions
Instruction Rd Rn Rm imm Restrictions
ADCS R0-R7 R0-R7 R0-R7 - Rd and Rn must specify the same register.
ADD R0-R15 R0-R15 R0-PC - Rd and Rn must specify the same register.
Rn and Rm must not both specify PC.
R0-R7 SP or PC - 0-1020 Immediate value must be an integer multiple of four.
SP SP - 0-508 Immediate value must be an integer multiple of four.
ADDS R0-R7 R0-R7 - 0-7 -
R0-R7 R0-R7 - 0-255 Rd and Rn must specify the same register.
R0-R7 R0-R7 R0-R7 - -
RSBS R0-R7 R0-R7 - - -
SBCS R0-R7 R0-R7 R0-R7 - Rd and Rn must specify the same register.
SUB SP SP - 0-508 Immediate value must be an integer multiple of four.
SUBS R0-R7 R0-R7 - 0-7 -
R0-R7 R0-R7 - 0-255 Rd and Rn must specify the same register.
R0-R7 R0-R7 R0-R7 - -
